Acid Resistant PPG lining

Name: Acid Resistant PPG lining
Brand: GOOD EARTH MINERALS PVT. LTD.
Price: 2500 INR
Availability: InStock

2500 INR/Square Meter

Get a Price/Quote

Product Details:

Application Process tanks, chemical plants, storage vessels, industrial pipelines
Usage Acid storage tanks, reaction vessels, chemical containment areas
Diameter Custom as per tank or equipment size
Load Capacity High mechanical strength
Material Grade Industrial
Machines Type Suitable for chemical processing machines
Purity High purity PPG material
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Acid Resistant PPG lining Price And Quantity

Minimum Order Quantity 150 Square Meter
Price 2500 INR/Square Meter

Customization Available for size, shape, and thickness as per project requirements
Elongation at Break >200%
Temperature Resistance -5°C to +110°C continuous service
Packaging Panels or rolls, securely packed for transportation
Tensile Strength Minimum 25 MPa
Water Absorption Negligible (<0.03%)
UV Resistance Good
Density Approximately 0.9 g/cm³
Service Life 10 years or more depending on conditions
Impact Resistance Excellent, suitable for industrial environments
Bonding Method Hot air welding, chemical adhesive
Anti-static Property Available as optional feature
Electrical Resistance High electrical insulation properties
Maintenance Low, easy cleaning surface

Acid Resistant PPG lining Product Specifications

Size Customizable as per requirement
Shape Sheet or Roll form
Feature Excellent chemical and acid resistance
Features Corrosion resistance, durable, easy to install
Surface Treatment Acid Resistant Coating
Thickness 2 mm to 10 mm
Product Type Acid Resistant PPG Lining
Machines Type Suitable for chemical processing machines
Main Material Polypropylene Glass (PPG)
Diameter Custom as per tank or equipment size
Material Grade Industrial
Load Capacity High mechanical strength
Usage Acid storage tanks, reaction vessels, chemical containment areas
Application Process tanks, chemical plants, storage vessels, industrial pipelines
Installation Type Bonded/laminated on substrate with adhesives
Form Solid lining
Weight Varies as per size and thickness
Color Grey
Purity High purity PPG material

Customization Available for size, shape, and thickness as per project requirements
Elongation at Break >200%
Temperature Resistance -5°C to +110°C continuous service
Packaging Panels or rolls, securely packed for transportation
Tensile Strength Minimum 25 MPa
Water Absorption Negligible (<0.03%)
UV Resistance Good
Density Approximately 0.9 g/cm³
Service Life 10 years or more depending on conditions
Impact Resistance Excellent, suitable for industrial environments
Bonding Method Hot air welding, chemical adhesive
Anti-static Property Available as optional feature
Electrical Resistance High electrical insulation properties
Maintenance Low, easy cleaning surface

Acid Resistant PPG lining Trade Information

Supply Ability 5000 Square Meter Per Week
Delivery Time 2-7 Days
Sample Available Yes
Sample Policy Free samples are available
Packaging Details AS PER REQUIREMENTS
Main Domestic Market All India
Certifications ISO 9001 : 2015

Product Description

GEFLOR PPGL

Polypropylene Glass Lined system.

GEFLOR PPGL is a chemical resistant lining system particularly for use in D.M water plants.

Copolymerized PP (polypropylene) sheets are fused with a glass woven fabric at high temperature. This inline bonding gives GEFLOR PPGL excellent bond strength. The glass fabric provides a base for application of resins and promotes adhesion and the Polypropylene face provides excellent chemical and U.V resistance. The composite also provides enhanced product performance with respect to improved mechanical resistance.

GEFLOR PPGL has excellent chemical resistance.

GEFLOR PPGL has good UV resistance.

GEFLOR PPGL has negligible joints.

GEFLOR PPGL has good abrasion resistance.

GEFLOR PPGL bonding compound is highly chemical resistant and has excellent adhesion to concrete compared to other PPGL linings available in the market.

Superior Chemical and Acid Resistance

Engineered for the most demanding environments, our acid resistant PPG lining delivers exceptional resistance to a wide array of chemicals and acids. With a robust acid resistant coating on high purity polypropylene glass, this lining is an optimal choice for facilities requiring long-term protection against corrosion and harsh substances.

Customizable for Your Project Needs

Every industrial setup is unique. Thats why we provide PPG linings which can be custom fabricated in thickness, shape, and size to precisely match your tank, vessel, or process pipeline dimensions. Choose from both panel and roll form to suit your facilitys requirements, ensuring seamless integration and optimal protection.

Easy Installation and Low Maintenance

Our PPG linings feature user-friendly installationthey can be bonded or laminated to substrates using hot air welding or chemical adhesives. Once installed, their easy-clean surface and low maintenance requirements contribute to reduced operational downtime and long service life, often exceeding ten years.

FAQs of Acid Resistant PPG lining:

Q: How is the acid resistant PPG lining installed on tanks or equipment?

A: The PPG lining can be installed by bonding or laminating it onto the substrate using hot air welding or specialized chemical adhesives, ensuring a secure, leak-proof fit. Our team provides comprehensive installation services and guidance for best results.

Q: What types of industrial applications are best suited for this acid resistant lining?

A: This lining is ideal for use in acid storage tanks, reaction vessels, industrial pipelines, chemical containment areas, and a variety of chemical processing machines. Its chemical resistance and mechanical strength make it suitable for harsh industrial environments.

Q: When should the anti-static feature be selected for the lining?

A: The anti-static property should be chosen for applications where static electricity could pose safety or operational concerns, especially with volatile chemicals or electronic-sensitive environments. It is available as an optional feature upon request.

Q: Where is customization available for this product?

A: We offer custom fabrication of size, thickness (2 mm to 10 mm), shape, diameter, and even packaging form (sheet, roll, panels) to fit specific project requirements for installations throughout India and for export.

Q: What is the typical service life of the PPG lining in industrial use?

A: The PPG lining is designed for a long service life, commonly lasting 10 years or more depending on usage conditions and maintenance. Its high durability and corrosion resistance ensure reliable long-term protection.

Q: How does the PPG lining benefit water and electrical resistance needs?

A: Our lining exhibits negligible water absorption (<0.03%), preventing moisture ingress, and has high electrical insulation properties, enhancing safety in environments exposed to liquids and electrical systems.

Q: What is the maintenance process for the acid resistant PPG lining?

A: Routine maintenance involves simple cleaning procedures thanks to its easy-clean surface. No special chemicals or equipment are needed, making upkeep straightforward and cost-effective.
